ISOMETER® isoPV485
Arbeitstemperatur ....................................................................................................... -25...+55 ºC
Klimaklassen nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) ...................................... 3K5 (ohne Betauung und Eisbildung)
Transport (IEC 60721-3-2)................................................... 2K3 (ohne Betauung und Eisbildung)
Langzeitlagerung (IEC 60721-3-1)...................................... 1K4 (ohne Betauung und Eisbildung)
Mechanische Beanspruchung nach IEC 60721:
Ortsfester Einsatz (IEC 60721-3-3) .......................................................................................... 3M4
Transport (IEC 60721-3-2) ....................................................................................................... 2M2
Langzeitlagerung (IEC 60721-3-1) .......................................................................................... 1M3
Anschluss
Anschlussart.......................................................................................................... Schraubklemmen
starr / flexibel /Leitergrößen AWG ................................................ 0,2...4 / 0,2...2,5 mm
flexibel mit Adernendhülse, ohne/mit Kunststoffhülse ......................................... 0,25...2,5 mm
Mehrleiteranschluss (zwei Leiter gleichen Querschnitts) starr/flexibel .. 0,2...1,5 / 0,2...1,5 mm
Abisolierlänge .................................................................................................................... 8...9 mm
Anzugsdrehmoment .................................................................................................... 0,5...0,6 Nm
Sonstiges
Betriebsart..................................................................................................................... Dauerbetrieb
Einbaulage ............................................................................................................................ beliebig
Schutzart, Einbauten/Klemmen (DIN EN 60529) .......................................................... IP30 / IP20
Gehäusematerial ......................................................................................................... Polycarbonat
Gehäusetyp / Maßbild............................................................................................................... X480
Schraubbefestigung................................................................................................................ 2 x M4
Schnellbefestigung auf Hutprofilschiene.......................................................................... IEC 60715
Entflammbarkeitsklasse .................................................................................................... UL94 V-0
Gewicht .............................................................................................................................. ca. 300 g
* Erläuterungen:
R
= Fehlerwiderstand zwischen IT-System und Erde (Gesamtwiderstand)
F
C
= Ableitkapazität zwischen IT-System und Erde (Gesamtkapazität)
e
Normen
Das ISOMETER® isoPV485 entspricht der Norm IEC 61557-8
Bestellangaben
Nennspg. U
Typ
AC 0...800 V*
isoPV485-421
DC 0...1000 V*
* Absolutwerte des Spannungsbereiches
Alle Rechte vorbehalten.
Nachdruck und Vervielfältigung
nur mit Genehmigung des Herausgebers.
Änderungen vorbehalten!
©
Bender GmbH & Co. KG
Bender GmbH & Co. KG
•
Londorfer Str. 65
35305 Grünberg
•
Postfach 1161
35301 Grünberg
4
2
Versorgungssp.
Art. Nr.
n
U
S
DC 12...72 V*
B 9106 8144
•
Germany
•
Germany
Operating temperature ................................................................................................ -25...+55 ºC
Classification of climatic conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3) ..........................3K5 (except condensation and formation of ice)
Transportation (IEC 60721-3-2) .........................2K3 (except condensation and formation of ice)
Storage (IEC 60721-3-1) .....................................1K4 (except condensation and formation of ice)
Classification of mechanical conditions acc. to IEC 60721:
Stationary use (IEC 60721-3-3) .................................................................................................3M4
Transport (IEC 60721-3-2) ........................................................................................................ 2M2
Storage (IEC 60721-3-1) ........................................................................................................... 1M3
Connection
Connection................................................................................................................ screw terminals
/ 24...12
rigid / flexible / conductor sizes AWG ............................................ 0.2...4 / 0.2...2.5 mm
2
flexible with ferrule without / with plastic sleeve................................................... 0.25...2.5 mm
2
Multi-conductor connection (two conductors of the same cross section)
rigid/flexible ................................................................................... 0.2...1.5 mm2 / 0.2...1.5 mm2
Stripping length ................................................................................................................. 8...9 mm
Tightening torque......................................................................................................... 0.5...0.6 Nm
General data
Operating mode ............................................................................................. continuous operation
Mounting ...................................................................................................................... any position
Degree of protection, internal components /terminal (DIN EN 60529) ........................IP30 / IP20
Enclosure material.......................................................................................................polycarbonate
Type of enclosure/dimension diagram......................................................................................X470
Screw mounting......................................................................................................................2 x M4
DIN rail mounting acc. to ...................................................................................................IEC 60715
Flammability class...............................................................................................................UL94 V-0
Weight ........................................................................................................................ approx. 300 g
* Explanatory note:
R
= fault resistance between IT system and earth (total resistance)
F
C
= leakage capacitance between IT system and earth (total capacitance)
e
Standards
The ISOMETER® isoPV485 corresponds to the requirements of the
IEC 61557-8 standard.
Ordering information
Type
isoPV485-421
* Absolute values of the voltage ranges.
Tel.: +49 6401 807-0
Fax: +49 6401 807-259
Supply volt.
Nominal volt. U
n
U
S
AC 0...800 V*
DC 12...72 V* B 9106 8144
DC 0...1000 V*
All rights reserved.
Reprinting and duplicating
only with permission of the publisher.
Subject to change!
©
Bender GmbH & Co. KG
E-Mail: info@bender-de.com
Web: http://www.bender-de.com
TBP106032deen / 08.2012
2
