RTW DigitalMonitor 10500X-PLUS
Short „S" 3 s
Integrated „I" Infinite
ITU-Bars Momentary+
Integrated
Silence Gate (I) –70 LUFS
Relative Gate (I) –8 LU
Peakhold 2.5 s
Start/Stop Control
Run on Startup
Alarm Threshold –15 LUFS
Alarm Hold 1 s
Dig-Errors press Sel to enter the submenu (description see Chap-
ter E 5.2.5.2)
Channel Mix Setup
press Sel to enter the submenu
(description see Chapter E 5.2.5.3.)
E 5 Menu • E 5.2 Modify Preset
Integration time constant for short display
with the S bargraph. Range: 1 s to 20 s
Longterm time frame for I bargraph. No ad-
justment available, controls according to the
settings of the Start/Stop Control option .
ITU-bargraph selection:
Momentary + Integrated
Momentary + Longterm
Integrated + Longterm
Threshold setting to avoid low loudness rea-
dings effect the longterm display of the I
bargraph. Range: –40 to –74 LUFS in steps
of 1 LUFS, Off
Threshold setting for the relative gate of the
I bargraph. Range: 0 to –39 LU in steps of 1
LU, Off
Peakhold reset time
2.5 s, 4.0 s, Man, Off
Selection of the Longterm time window.
• Internal: Start and Stop keys for
manual control (Func 1
and Func 2 in ITU/EBU
mode of Program Meter)
• External: Start/Stop manual by the
use of external keys
• Run on Startup: permanent measurement
Threshold setting for loudness alarm display.
The setting is connected to the target level,
its range contains ten steps of 1 LUFS
upwards. (Example: TL: –23 LUFS,
AT: –23 LUFS to –14 LUFS)
Alarm reset time: OFF, 1 s to 9 s
