RTW 10500X-PLUS Bedienungsanleitung Seite 154

See Fig. E 3-2
See Chapter E 3.5
RTW DigitalMonitor 10500X-PLUS
In the main menu (see Fig. E 3-2) you will see the following three options
which can be accessed using the Up/Dwn (Down) keys and entered with
the Sel (SELECT) key:
• Use Preset
Use the Use Preset option to load a factory or user preset for the MODE/
SET button that was used to enter the menu. Press the Sel (SELECT) key
repeatedly to select the preset of your choice.
Note:
The Use Preset option only selects the preset for the MODE/SET but-
ton previously chosen, not for the other one. In case you want to define
the preset for the other mode please leave the menu with Quit and press
the other MODE/SET button. After this you can access the menu again
by pressing the same MODE/SET button for more than 1 second and
select the preset for this mode.
• Modify Preset (submenu)
Selecting Modify Preset enters a submenu with detailed configuration
options for all three display sections (Program Meter, Multi Instrument 1
and Multi Instrument 2). The configuration changes made here can be
saved in one of the user presets U1 - U8 (see Chapter E 3.5) before
leaving the menu.
• General (submenu)
Selecting the General option enters a submenu with several global system
options.
E 3 Quick Start • E 3.3 Menu Access 154
