See Chapter E 5.2.2
RTW DigitalMonitor 10500X-PLUS
5. Make the appropriate changes.
Note:
For details about the available parameters please refer to the accor-
ding topics in Chapter E 5.2.3: more .. for Program Meter: PPM (PPM
Digital menu).
6. When done, press Quit to enter the Save Preset screen.
7. If you want to discard any changes, press Quit again to leave menu mode
without changes. If you want to save your selection in a user preset, use
Up or Dwn key to set the cursor on the Store to selection and toggle
through all available user presets with the Sel (SELECT) key.
Note:
There is no copy protection for the presets. Be sure not to destroy a
setup that might be used by another operator.
8. If you would like to name your preset, use Up or Dwn key to set the cursor
on the Preset-Name selection. With the Sel (SELECT) key you can toggle
through a bank of characters. Once you have found the desired charac-
ter move the cursor to the next character of the preset name using the
Rgt key. Select the second character in the same way using the Sel (SE-
LECT) key. Proceed until you have created your preset name.
9. Use Up or Dwn key to set the cursor on the Press SEL to SAVE selection
and use the Sel (SELECT) key to store the preset. This returns you to the
normal display operation of the DigitalMonitor 10500X-PLUS with the new
preset loaded.
E 4 Display Modes • E 4.1 Program Meter: PPM mode 165
