2.3

Connecting Points for Breathing Apparatus

The back plate of the breathing apparatus must only be connected at the points pro-
vided for that purpose and only with the connecting pieces delivered with the har-
ness.
Only the following self-contained breathing apparatus may be attached:
- AirMaXX
- AirGo
Observe the oeprating manual of the respective breathing apparatus.
Any configuration of above breathing apparatus can be used. However, the weight
of the complete operational unit must not exceed 16 kg. This explicitly excludes the
simultaneous use of two compressed air cylinders.
alphaFP pro
(1) Remove existing harness from backplate.
(2) Fasten alphaFP harness onto backplate according to the following pictures.
Shoulder connection
GB
alpha FP pro/alpha FP basic
Description
Hip belt connections
9
