Fig. 1:
Connection to electricity
The cabinet is intended for connection to alternating current. The connection voltage (V) and
frequency (Hz) are shown on the name plate in the cabinet .
Power connection is made by a three pin plug to a wall socket.
Any requirement for earthing from the local power supply must be met. The cabinet plug and
wall socket should then give a correct earthing. If you are in doubt, approach your supplier or
authorized electrician.
Warning - this appliance must be earthed
The flexible cord fitted to this appliance has three cores for use with a 3-pin 13 Amp plug. If a
B.B. 1363 (13 Amp) fused plug is used, it should be fitted with a 13 Amp fuse.
Important
The wires in this mains lead are coloured in accordance with the following code:
Green-and-yellow: earth
Blue: neutral
Brown: live
