Electrical connections

• PowerValue 11 RT 6 kVA (see Fig.6)
Legend
1 GND contact
2 EPO
3 Parallel port
4 Output circuit breaker
5 Output sockets
6 SNMP/ AS400 slot
7 USB
8 RS232
9 Bypass
10 AC input
11 AC output
• PowerValue 11 RT 10 kVA (see Fig.7)
Legend
1 SNMP/ AS400 slot
2 EPO
3 USB
4 Parallel port
5 Battery connector
6 GND contact
7 Output sockets
8 Output circuit breaker
9 AC output
10 Bypass
11 AC input
