GB
A petrol suction pump (plastic, available from DIY
stores)
An oil can with hand pump (available from DIY
stores)
Engine oil
Assembly
1. Fasten the push handle (Fig. 3a / Item 2) with one
screw (Fig. 3a / Item 8) and one nut (Fig. 3a / Item
7) each on either side, making sure that the cable
pulls to be installed later on are not in the way.
2. Unfold the push bar and fix it into place by
tightening the star screws as shown in Figure 3b.
3. Insert the grip of the starter cord (Fig. 3c/Item 5)
into the hook provided for that purpose as shown
in Figure 3c.
4. Fasten the cords to the push bar with the
supplied cable clip (Fig. 3d/Item 6).
5. Lift the ejector flap (Fig. 4 / Item 4) with one hand
and hook in the grass bag (Fig. 4/Item 3) as
shown in Figure 4.

6.2 Setting the cutting height

Important. Adjust the cutting height only when
the engine is switched off and the plug boot has
been pulled.
Before you begin to mow, check to ensure that
the blade is not blunt and that none of the
fasteners are damaged. To prevent any
imbalance, replace blunt and/or damaged blades
as a set only (if applicable). To carry out this
check, first switch off the engine and pull the
spark plug boot.
The cutting height is not adjusted at a single
central point – instead, each of the 4 wheels
have to be adjusted separately. Three different
cutting heights are available. (As-delivered state:
Medium cutting height)
Caution: All 4 wheels have to be set to the same
cutting height.
1. Lever out the wheel cap from the wheel by
applying a screwdriver in the opening provided
(Fig. 6a)
2. Open the wheel bolt (Fig. 6b).
Important: The wheel bolts have a right-handed
thread on the right-hand side and a left-handed
thread on the left-hand side.
Important: There is a metal washer between the
wheel and the mower housing. Make sure that
you fit this washer back in place between the
wheel and the housing during reassembly.
We recommend that you first change both
wheels on one side followed by both wheels on
the other side.
24
29.07.2010 10:43 Uhr Seite 24
3. Remove the wheel and screw it back on tightly in
the desired position (Fig. 6c)
Position 1: Low cutting height
Position 2: Medium cutting height
(As-delivered state (sufficient for normal use)).
Position 3: High cutting height
4. Fit the wheel cap back on again and follow the
same procedures to adjust the other 3 wheels to
the same height and position.
7. Using the petrol lawn mower
Important.
The engine is supplied without oil and petrol.
Therefore, be sure to add oil and petrol before
starting the engine.
In order to avoid any unintentional start-ups of the
lawn mower, it comes equipped with an engine brake
(Fig. 5a/Item 1) which must be pulled back before the
engine can be started. When the engine start/stop
lever is released it must return to its initial position, at
which point the engine automatically switches off.
Whenever you need to perform any kind of
adjustment and/or repair work on your lawn mower,
wait until the blade has come to a complete stop.
Always switch off the engine before carrying out any
adjustments, maintenance or repairs.
Note:
1. Engine brake (Fig. 5a/Item 1): Use the engine
start/stop lever to switch off the engine. When
you release the engine start/stop lever, the
engine and blade will automatically stop. To mow,
hold the lever in the working position (Fig. 5b).
Before you start to mow, check the start/stop
lever several times to be sure that it is working
properly. Ensure that the tension cable can be
smoothly operated (i.e. is not catching or kinking
in any way).
2. Warning: The blade begins to rotate as soon as
the engine is started.
Important: Before you start the engine, move the
engine brake several times to be sure that the
stop cable is properly working.
Note: The engine is factory set to a speed that is
optimal for cutting and blowing grass into the
basket and is designed to provide many years of
use.
3. Check the oil level.
4. Use a funnel and measuring vessel to fill the tank
with petrol. Make sure that the petrol is clean.
