4. Installation Instructions

Installation
Installation should only be undertaken by a manufacturer approved technician.
The use of an unapproved installer may invalidate the warranty.
During installation, all consumables should have been added to the machine as
approriate. It is important to check that this has been undertaken before starting
the machine. See section 6 for care and maintenance details.
A separate pre-installation checklist should have been supplied by your dealer.
Please review this prior to approving installation.

Unit overview

Cover
Upper Load
Basket
(Optional)
Upper Trolley
Lower Load
Basket
(Optional)
Lower Trolley
Door
Rear of Unit
Power
connector
Cold Water
Inlet Hose
RO Water
Inlet Hose
Ethernet
Connector
Printer
Connector
Fuse Holder
Drain Hose
Hot Water
Inlet Hose
6
USB
Port
Touch
Screen
On/Off
Switch
Chemical
Drawer
Kickplate
