Operating instructions
• The fan head can be locked in a stationary position or oscillate (side-to-side sweeping
motion). The fan head can also be tilted.
• Press the knob (6) for oscillation, which spreads airflow evenly over a wider area.
Pull up the knob (6) to lock the fan in a stationary position.
• 2-speeds. Use the buttons (7) to set the speed (H or L).
• Press [ OFF ] to turn off the fan.

Care and maintenance

• Use only a damp cloth when cleaning; never use strong cleaning agents or solvents.
• Use a vacuum cleaner and clean through the openings in the grille to remove dust
if needed.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

Specifications

Voltage
Wattage
Protection class
Description
Maximum fan flow rate
Fan power input
Service value
Standby power consumption P
Fan sound power level
Maximum air velocity
Measurement standard for
service value
220–240 V AC, 50 Hz
25 W
IPX0
Symbol
F
P
SV
SB
LwA
c
IEC 60879:1986 (corr.1992)
5
Value Unit
15.67 m³/min
17.5 W
0.90 (m³/min)/W
— W
53.80 dB (A)
1.86 metres/sec
