Leckey Mygo Max Benutzerhandbuch Seite 9

Open up the angle of the leg supports by
unscrewing the knobs (A), shown, and set to
the maximum width. Open the socket caps
(B) and slide in the calf supports. Set to the
desired position, with the footplates facing
forward and retighten the socket cap bolts
with the multi-tool.
A
B
Adjust the height of the chassis to its
maximum to reduce risk of back strain while
attaching the seat unit. Refer to Section 11
on how to adjust the height of the chassis
you have purchased.
First release the safety locking pin at the
front of the seat. To do this pull the pin out
and rotate through 90 degrees. Carefully lift
the seat and place it into the chassis. At the
rear of the underside of the seat you will see
a receiving channel. Place this securely over
the tube towards the back of the chassis.
Pull the handle at the front of the seat unit up
and then pivot the seat forward and down.
