To adjust the height, depth or angle of the
standard sacral support, loosen the two
screws (a) on either side of the bracket,
move to the required position and retighten
the screws.
To adjust the height or depth of the ball &
socket sacral support, loosen each screw
(a) on either side of the bracket, move to the
required position and retighten the screws.
To adjust the angle, loosen both the screws
(b) on the ball and socket joint. Position the
support at the required angle and retighten
the screws.
A
Loosen the bolts (a) to adjust the width,
height and angle of the lateral supports
and retighten when you have achieved the
desired position.
Adjust width, height and angle as above. The
laterals can be flipaway by pulling pin (b).
The complex laterals can be used in
whatever combination is most suited to the
user's requirements. To adjust the height
width and angle of these laterals, loosen bolt
(a) and retighten when you have achieved the
A
B
A
B
