The hip laterals can be width and angle
adjusted to suit the user's requirements.
Loosen the screws (a) at the back of the
sacral support. Move the hip laterals to
required position. Ideally the hip laterals
should always be rotated so they rest on
top of the seat cushion even if the backrest
or sacral support is angled. Once the hip
laterals are in position, retighten the screws
securely. The laterals can also be angled
to help support, abduction adduction or
windsweeping.
B
To adjust the angle of the hip laterals loosen
the screw (b) on the hinge of the hip lateral.
Adjust to the required angle and retighten
the screw. The pads can also be adjusted
in depth and a small degree of rotation by
loosening the screws (c) on the pad, sliding
it to the required position and retighten the
screws.
A
C
