2. Install the Force Applicator and advance it until a gap on the carrier shaft becomes visible
between the Stop Wheel and the face of the ratchet.
This check is important. It facilitates clamp application and removal. This starting
position is necessary to allow removal of the clamp from the patient following the
procedure.
3. Press the Stop Wheel toward the Force Applicator until it registers as illustrated in Figure 15.
Figure 15 Clamp Application and Removal Check
Figure 14 Installation of Force Applicator
WARNING!
Page 16
