Symbols used in the brief
instructions
Download the KÄRCHER
Home&Garden app
Gateway boot process
Commissioning via the app
Reset
Power connection
Network connection
Switch the water outlet on/off
Take care to observe the safety
instructions provided.

Commissioning

Note: Commissioning is performed via the
KÄRCHER Home&Garden app. Please be
sure to follow the instructions provided in
this app to be sure that you are up to date.
Note: The watering valve requires 4 x 1.5 V
AAA batteries. These are not included in
the scope of delivery. Additional information
on the batteries is provided in the "Techni-
cal data" chapter.
Starting up the gateway
1. Load the KÄRCHER Home&Garden
app from the Apple App Store or from
the Google Play Store.
2. Open the KÄRCHER Home&Garden
app.
3. Switch to "Add product".
4. Create an account (if you are not already
registered).
5. Insert the hollow plug of the power sup-
ply into the gateway socket.
6. Plug the power supply into a power
socket.
The boot process starts and can take
several minutes.
7. Scan the QR code of the gateway.
8. Select "Kärcher-Gateway" as the access
point in the WLAN search on your smart-
phone.
9. Enter the previously scanned QR code
of the gateway as the WLAN password
or manually enter the WPA key on the
type plate of the gateway.
10.The connection is checked when you re-
turn to the KÄRCHER Home&Garden
app.
11.Select the home network and enter the
password.
Correct installation is confirmed if the
connection test is successful.
Note: Position the gateway in the same
floor of your home and as close as possible
to the watering valve. The optimum position
is at a window.
Important: If a MAC filter or additional fire-
wall is set up in your WLAN router then you
must enable the MAC address of the gate-
way in your router. The MAC address is
specified on the type plate of the gateway.
