3.8.2.2 – Electrical system
Diagram in section 8.3/8.4. Every control unit is wired by connecting
Black/brown
Black/Blue
Black/Grey
Black/Red
The ''before use'' button starts the pump, whilst the ''after use'' pump starts a program, which
activates the pump before starting the toilet motor and then activates the pump again for the final
rinse.

3.8.3 - System with integrated Bidet

The integrated bidet option offers the possibility to use the toilet in a dual mode: toilet and bidet.
The special spray nozzle has been designed to connect separately the fresh water for the toilet
flush and the water for the bidet function mixed and controlled with an elegant handle also
provided.
On most configurations, the mixer and the handle are integrated in the ceramic toilet body , while
on the toilet design Privilege and Evolution they are installed remotely wall mounted.
(see technical sheets to verify the type of integration possible for each model - integrated or wall
mounted)
Connect hot and cold water from the fresh water system to the mixer.
Use the handle to adjust the flow and the temperature of the water.
Whereas integrated in the ceramic the mixer/handle is always positioned on the right hand side.
Whereas wall mounted (Privilege/Evolution) the default length of the hose is 60cm, while this can
be elongated by the shipyard according to the specific needs
Mixer and handle technical specifications:
Hot water connection
Cold water connection
Mixed water to toilet nozzle
Mixer body diameter
Flange
Handle
Hadware
TECMA SRL – Via Flaminia / Loc Castel delle Formiche/ 05030 Otricoli (TR) / Italy-
Manual rev1.6.2015 1111111111111111
toilet motor
Inlet pump
Tank sensor
Power supply (with fuse on the red wire)
3/8"
3/8"
3/8"
O.D. 42mm
O.D. 60mm
Standard
gaskets + mounting screws
