Tecma Privilege Bedienungs- / Installations- / Wartungshandbuch Seite 148

Operation/installation/service manual
Manuale di utilizzo / installazione / manutenzione
X-light / Privilege/ Evolution/ Breeze/ E-Breeze/ Silence Plus 2G/ Elegance 2G
Working pressure recommended
Solenoid Inlet and Outlet (threaded female)
Toilet hose inlet fitting (barbed)
Single system (Raw water)
Toilet hose inlet fitting (barbed)
12V DC
24V DC
110-125V AC 60Hz
220-240V AC
50Hz or 60 Hz
TECMA SRL – Via Flaminia / Loc Castel delle Formiche/ 05030 Otricoli (TR) / Italy-
Manual rev1.6.2015 1111111111111111
INLET SOLENOID
12V DC
Centralized system
Power consumption 9.5 W
INLET PUMP
12V DC
Fuse 8 A
Pressure
Water flow 12 l/min
WIRE GAUGE SIZE CHART
Distance from source* is:
0.1-2 m ( >80'')
11 AWG (4.17 mm2)
13 AWG (2.63 mm2)
18 AWG (0.82 mm2)
18 AWG (0.82 mm2)
*Distance measured assumed power and ground wires
24V DC
10 W
3 bar 3 bar
1/2"
1/2"
24V DC
4 A
45 PSI - 3 bar
3.17 gmp
1/2"
80 -160''
9 AWG (6.63 mm2)
11 AWG (4.17 mm2)
18 AWG (0.82 mm2)
18 AWG (0.82 mm2)
111111111111111111111
MACERATOR TOILETS
TOILET MACERATRICI
110-125V 220-240V AC
AC 60Hz 50Hz or 60 Hz
6 W 6 W
3 bar 3 bar
