Installation instructions, for professionals only

6.4. Foil sensor

DIP-Bank 4
Function selection switch 3
If an infrared plate is connected to the infra-
red output, the WC4-IRF-F foil sensor must
be used. The foil sensor must be activated
according to the adjacent figure by putting
switch 3 to ON.
Fig. 12: Foil sensor
p. 24/44
ON
OFF
