Installation instructions, for professionals only
Switching: Switching the infrared heater or infrared plate with a heating capacity
of max. 3.5 kW. No dimming funcion.
Leading edge phase control: Controlling (dimming) the infrared heater/infrared
plate is possible in 5 levels up to 350 W.
Half-wave control: Controlling (dimming) the infrared heater/infrared plate is
possible in 5 levels up to 1.3 kW.

6.3. Operating time

DIP-Bank 1
Function selection switch 5 – 8
The maximum operating time is set to
6 hours as standard. The infrared con-
troller shuts down automatically after the
maximum heating period for safety reasons.
The function selection switch in the low-
voltage connection area can be adjusted to
the maximum operating time. The required
positions of the function selection switch
can be found in the following table.
!
The EN 60335-2-53 specifies a maximum heating period limit of 6 hours
for private saunas. For saunas in hotels, apartment blocks and similar
locations, a maximum heating period limit of 12 hours is permissible.
Extending the heating period limit to 18 hours or 24 hours is only per-
mitted in public saunas.
Fig. 11: Operating time
p. 22/44
ON
OFF
