Technical Data; Characteristic Data Of The Evaluation Device; Characteristic Data Of The Sensor - ACO Haustechnik Multi Control Gebrauchsanleitung

Grease layer thickness measuring device Multi Control

Technical Data

8 Technical Data

8.1 Characteristic data of the evaluation device

Characteristic data
Power supply:
Display:
Consumption:
Input elements:
Resolution level:
Circuit board size:
Switch outputs:
Storage:
Clock function:
Connection cable length:
Cable feeds:

8.2 Characteristic data of the sensor

Characteristic data
Power supply:
Heating:
Temperature regulation:
Circuit board size:
Maximum cable length:
Cable connection on the sensor:
68/ 72
Description
External wide-range power supply:
input: 100 – 240 VAC 50/60 Hz
■
output: 24 VDC
■
Backlit LCD
approx. 43W
Operating keys (+ / - / Enter)
< 10 %
approx. 100 x 100 mm
3, relay 2 with adjustable threshold max. load 230 V AC/DC 2A
internal + external (on an SD card) recording of times, when a change in the
yes, with backup battery CR2032 in battery compartment, time set ex works
3m
PG-glands
Description
24VDC from the display device
PTC or R 40W (for 24 VDC)
approx. 70 °C processor controlled temperature sensor (NTC) + switching
FET
21 mm x 120 mm
30m
Plug
