Product Description

2.1 Product features

2.1.1 Technical features

Implementation of grease separators for free-standing installation
Measuring rod with capacitive sensor (200mm measurement range)
■
Heatable section of the measuring rod for the measuring of grease layer thickness
■
Evaluation device with touch panel
■
Clamp fixing for the evaluation device on the measuring rod
■
Compression fitting with sealing and counter-nut for attachment to the grease separator
■
Implementation of grease separators for below ground installation
Measuring rod with capacitive sensor (200mm measurement range)
■
Heatable section of the measuring rod for the measuring of grease layer thickness
■
Evaluation device with touch panel
■
Wall mounting for the evaluation device
■
■

2.1.2 Operating features

Capacitive measurement of the grease layer
■
Adjustable temperature
■
Adjustable pre-alarm (for example, schedule the disposal process at measurement of
■
75%)
Adjustable full alarm (carry out disposal process at measurement of 100%)
■
Automatic display of the pre- and full alarm
■
Recording of the developing grease layer thickness on an SD card or other external
■
storage media
Grease layer thickness measuring device Multi Control
