Grease layer thickness measuring device Multi Control
2.2.2 Implementation of grease separators for below
ground installation
16
15
14
13
12
11
10
9
8
7
1 = Touch-Panel *
(e. g. screwdriver)
3 = Flap part
5 = Terminal compartment *
6 = 3 m connection cable with power adapter
7 = Heating and measuring range
8 = Scale
* Inside the analysis device
Product Description
9 = Cable screw connection (connection routing
operating message and error message)
10 = Analysis device
11 = Fixing bolts
13 = Connecting cable (10 m, 20 m or 30 m long)
14 = Cable screw connection
15 = Holder
16 = Fixing bolt (EJOT)
1
2
3
4
5
6
47/ 72
