Grease layer thickness measuring device Multi Control

4.3 Lay the connecting cable

location (the technical room) of the evaluation device.
Requirements:
Leave the sufficient length of connecting cable in its housing, so that the "measuring
■
rod" unit can be removed from the shaft construction.
Keep sufficient excess length of the connecting cable (ca. 0.5m), to protect the wiring
■
Fasten the connecting cable into the cable gland, move into the in-situ "supply line" and
lay up to the installation location,

4.4 Electrical installation

WARNING
Risk of electric shock due to live parts
The evaluation device must not be connected to the power supply until the
■
assembly work and electrical installation have been completed.
Work on electrical connections must be carried out by qualified electricians
■
only.
Electrical connections must be carried out in accordance with the circuit
■
diagram,
Chapter 8.4 "Circuit diagram".

4.4.1 Electrical data

Chapter 8.1 "Characteristic data of the evaluation device"

4.4.2 Mounting the evaluation device

Requirements:
Flood-proof and open wall surfaces of at least 250mm x 250mm (W x H)
■
■
Mount the evaluation device to the wall with the in-situ materials.
4.4.3 Electrical installation
manufacturer's instructions.
Set up group alarm. The evaluation device has three isolated contacts for the
transmission of two operation signals (pre- and full alarm) and a group alarm. For
onward transmission a conduit must be connected to the evaluation device.
Installation of below ground separators
instruction manual "Lipumax P".
55/ 72
