Installation of below ground separators

WARNING
Risk of falling through open manhole covers
■
Hazard from gases
■
Adequately ventilate the interior before entering.
■

4.1 Preliminary work

4.1.1 Mount the measuring rod to the mounting

as-delivered separator.
Insert the measuring rod through the
bore hole of the mounting (1).
fitting with fixing material, establish a
screw connection and tighten fingertight
(2)

4.1.2 Adjust measuring rod

Due to differing nominal sizes there are varying adjustable heights for the measurement range.
The following values should be used for ACO Building Drainage below ground grease separator
(Lipumax P).
Grease layer thickness measuring device Multi Control
