Grease layer thickness measuring device Multi Control
Product Description

2.3 Operating principle

The grease layer, which builds up in the grease separator, is in contact with the measuring rod
(sensor). A capacitive measurement of the thickness of the grease layer between the range of
advance warning (e.g. 75%)
■
full (e.g. 95%)
■
the disposal of the contents of the grease separator can be scheduled and carried out in good
time.
IMPORTANT
grease measurement range of the Multi Control, the vertical position of the measuring rod will be
altered so that the last 200 mm of the developing grease layer will be measured.
48/ 72
850
4
3
2
1
800
9
8
7
6
5
4
3
2
1
700
9
8
7
6
5
4
3
2
1
600
9
8
7
6
5
4
3
2
1
500
100 %
0 %
type plate) exceeds the
