7.10 Attaching the
Hip Laterals
To attach the hip laterals to the sacral
support, loosen screw (a) and insert the bar
of the hip lateral into the hole on the side
of the sacral support. Tighten the screw to
secure.
A
7.11 Attaching the
ankle huggers
Slide the webbing through the slot in the
sandal. Loop the webbing back up and
through the bottom of the triglide. Then pass
the webbing through the top of the triglide.
Finally to lock the webbing in place, pass it
through the bottom of the triglide again.
Trim strap to required length.
1
2
3
4
7.12 Attaching the
protraction pads
To attach the protraction pads, remove
screw (a) from metal bracket on the standard
lateral. Place the protraction pad on top of
the bracket and replace with the new longer
screws which are included. Retighten using
the allen key. Attach to the seat as per 7.5.
A
