7.6 Attaching the
Leeway Pelvic Cradle
Fasten the front buckle and side.Velcro tabs
of the Leeway Pelvic Cradle. Attach the four
side release buckles (a), two at the back of
the seatbase and two at the side.
A
7.7 Attaching the sandals
If sandals are required they can be attached
to the footplates with a single fixing bolt.
To position the sandals simply loosen the
knob (a) under the footplate, select the
position you require and re-fasten the knob.
A
7.8 Attaching the
armrests
Slide the armrest into the receiving bracket.
Adjust to the required height and retighten
the knob.
7.9 Attaching the Tray
The tray is attached to the seat by inserting
the tray tubes through the centre of each
armrest. Once the tray is located in the
position the knob (a) should be tightened
securely.
A
