DESCRIPTION OF THE DEVICE

Features

Ultra-flexible LED colour-changing bar
• 6, 15, 60 or 63 DMX channels selectable for numerous applications
• Equipped with 60 x 1 W LEDs: 20 x red, 20 x blue, 20 x green
• High power LEDs made by Lumileds, USA
• 100 000 hours LED life
• Each LED can be controlled individually
• Switch-mode power supply
• Automatic power supply adaption between 90 and 260 Volts without power selector
• Stepless RGB colour changing
• Programmable color-change speed and strobe effect
• DMX-controlled operation or stand alone operation with Master/Slave-function
• Strobe-effect with 1-18 flashes per second
• Programmed chaser
• 8 built-in programs can be called up via DMX-controller or dip switches
• Sound-controlled via built-in microphone
• Rainbow-effect with adjustable speed
• Dip switches for adjusting the DMX-starting address and stand alone programs
• Advantages of LED-technology: extremely long life, low power consumption, minimal heat emission,
defacto maintenance free with brilliant light radiation
• DMX-control via every standard DMX-controller

Overview

(1) Fixation screw
(2) Housing
(3) LEDs
(4) Mounting bracket
(5) Floor-stand
(6) Safety eyelet
(7) DMX-In socket
(8) DMX-Out socket
(9) Power output
(10) Power input / Fuseholder
(11) Power switch
(12) DIP-switches
