ENGLISH
 The display shows "MId" to indicate that the receive mode is active.
 The Scenemaster does NOT send any MIDI-commands, it only listens to incomings MIDI-data.
 Except for the BLACKOUT button (9) pressing buttons and moving faders has no effect.
Only the BLACKOUT-button (9) is still active:
 Press the BLACKOUT-button shortly: DMX-output goes in blackout but scenes are still active.
 Press the BLACKOUT-button for 2 seconds: all scenes are switched off. (in case something goes wrong
in the MIDI-communication)
MIDI COMMANDS
Switching scenes on/off:
Fading scenes gradually:
Blackout function:
Remark: "n" = MIDI channel.
kk Function
0-15 SCENE1-16
16-31 SCENE17-32
32-47 SCENE33-48
48-63 SCENE49-64
...... ......
125 MASTER
126 BLACKOUT
...... ......
HOW TO USE - AS MIDI-CONTROLLER
If needed, updating the firmware in the Scenemaster is easy, just follow these steps:
 Surf to the Scenemaster product page on our website (www.jbsystems.be) to check if new firmware is
available in the download section.
 Download the file and unzip it: now you have a file named "SCM-1.SUP"
 Put this file in a directory on your PC.
 Connect the Scenemaster to one of the USB-inputs of your PC.
 Turn the power of the Scenemaster OFF.
 Press the "FLASH-button of channel 16" and the "PROGRAM-button" (8) together while you switch the
Scenemaster back on, you will notice 2 things:
 The display on the Scenemaster shows "USb"
 A new window, with directory named "SCENEMASTER" opens on your PC-screen.
 This "SCENEMASTER" directory contains a file named "SCM-1.SUP":
 First delete the current file from the "SCENEMASTER" directory.
 Now copy the new "SCM-1.SUP" file (downloaded from our website) in the directory.
 Use the power switch (14) to switch the Scenemaster off.
 After 5 seconds turn the unit back on: at startup the display will show the new software version.
Important remark: do NOT switch the Scenemaster off while no new file was copied to the
"SCENEMASTER" directory, this will make the Scenemaster inoperable.
JB SYSTEMS
®
0x9n kk 127
0xBn kk vv (vv: 0-127)
0x9n kk 127
Function explain
Turn on/off and fade in/out Scenes 1-16(UNIT 1)
Turn on/off and fade in/out Scenes 17-32 (UNIT 2)
Turn on/off and fade in/out Scenes 33-48 (UNIT 3)
Turn on/off and fade in/out Scenes 49-64 (UNIT 4)
......
Master fader in/out (ALL UNITS)
Turn on/off Blackout (ALL UNITS)
......
