F. Use the SCENE/MANUAL button (4) to set the controller again to "SCENE".
G. To save the changes, keep the PROGRAM button (8) pressed while you press the FLASH button (2) of
the scene with flashing status led (3). (the leds flash 3x to confirm that the scene was saved)
H. If you want to edit other scenes, just repeat steps B to G.
I. Press the SCENE/MANUAL (4) and PROGRAM (8) buttons again to stop "program mode" (the red
"program LED" turns dark)
Remark: you can move a channel fader up and down to unlock it and set a new value. If you close the
channel fader, the original value remains unchanged.
DELETE SCENES
Any programmed scene overwritten by a new scene or deleted. Deleting a scene is in fact nothing more than
overwriting it with an empty scene:
A. Scenes can only be deleted while the unit is set in "program mode". So first enter "program mode" by
pressing the SCENE/MANUAL (4) and PROGRAM (8) buttons together  red "program LED" is lit.
B. Use the SCENE/MANUAL button (4) to set the controller to "MANUAL".
C. Use the CHANNEL faders (1) to make an "empty scene": all faders are closed + status leds are dark.
D. Keep the PROGRAM button (8) pressed (status leds of channels with scenes are lit): and push the
FLASH buttons (2) of the scenes that you want to remove. The status leds (3) of the deleted scenes will
turn dark.
E. Press the SCENE/MANUAL (4) and PROGRAM (8) buttons again to stop "program mode" (the red
"program LED" turns dark)
HOW TO USE – MIDI FUNCTIONS
MIDI CHANNEL SETUP
To ensure that the controller sends/receives MIDI-data on the desired channel, follow these steps:
 Press the DISPLAY MODE button (6) for about 3seconds, until the led starts flashing.
 Use the MASTER fader (7) to select the desired MIDI-channel. (01 to 16)
 Press the DISPLAY MODE button (6) for about 3seconds, until the led stops flashing.
Done!
MIDI OUT FUNCTION (USE AS MIDI CONTROLLER)
Used to control all kinds of MIDI-applications. For example you can use the Scenemaster to control:
 Video software like: Arkaos GrandVJ, Resolume, and many other ...
 DMX light software like: DMX-Creator, Daslight, Sweetlight, and many other ...
 All kinds of other MIDI controllable applications.
In both scene mode and manual mode MIDI is sent. (DMX and MIDI can be used together)
Just use the CHANNEL faders (1), MASTER fader (7) and FLASH buttons (2) to control your MIDI-
applications running on PC. (MASTER fader only works on unit 1)
Remark: use the DISPLAY button (6) to switch the display to MIDI-values (0-127).
MIDI COMMANDS
Control Change messages are sent with status 0xBn kk vv, where n is the MIDI-channel, for the specified CC
controller. Thus the controller MIDI ID is indicated with the channel along with the CC number.
kk Button and fader
0-15
Button and Fader 1-6（UNIT 1）
16-31
Button and Fader 1-16 (UNIT 2）
32-47 Button and Fader 1-16（ UNIT 3） Button(0/127) and Fader(0--127) 1-16 value（ UNIT 3）
48-63 Button and Fader 1-16（ UNIT 4） Button(0/127) and Fader(0--127) 1-16 value（ UNIT 4）
...... ......
125 Master fader（ UNIT 1）
126 Blackout button
...... ......
MIDI IN FUNCTION (CONTROLLED BY EXTERNAL MIDI CONTROLLER)
Up to 64 scenes can be controlled by MIDI-controllers and sequencers, perfect for musicians.
The Scenemaster should be set in "MIDI RECEIVE" mode: press the SCENE/MANUAL-button (4) and
DISPLAY MODE-button (6) together.
In "MIDI RECEIVE" mode:
JB SYSTEMS
®
vv (0-127)
Button(0/127) and Fader(0--127) 1-16 value（ UNIT 1）
Button(0/127) and Fader(0--127) 1-16 value（ UNIT 2）
......
Master fader value（ Only UNIT 1）
0/127 （ Only UNIT 1）
......
