ENGLISH
OPERATION MANUAL
Thank you for buying this JB Systems
operating instructions very carefully.
FEATURES
This unit is radio-interference suppressed. This product meets the requirements of the current European and
national guidelines. Conformity has been established and the relevant statements and documents have been
deposited by the manufacturer.
 Extremely user-friendly 16channel DMX controller for all kinds of applications: stage, DJ, architectural
lighting, ...
 Seamless linking of up to 4 units to obtain a virtual controller with maximum 64channels and/or scenes!
 2 user modes:
 Dimmer mode: you can control 16 dimmer channels gradually (extendable up to 64channels)
 Scene mode: you can create 16 scenes, each containing 16channels (extendable to 64scenes,
each containing 64channels)
 MIDI functionality via USB (16ch):
 MIDI OUT: all channel faders + flash buttons can also send out MIDI-commands so you can control
different MIDI applications (ex. Arkaos, Resolume, DMX-Creator, Daslight, ...)
 MIDI IN: all scenes (16 up to 64) can be controlled by any external MIDI controller (seamless
integration with MIDI-software such as Cubase, etc.), perfect for musicians etc.
 The channel faders can be used to mix several scenes together.
 Push buttons on top of all dimmer channels:
 Dimmer mode: used as flash buttons
 Scene mode: scenes can easily be switched on/off
 Blackout function
 Last output is preserved while the unit is switched off and on again (no need to push any button or de-
active blackout): perfect for use on exhibition booths, shops, ...
 4-digit LED-display shows DMX-values (0-255 or 0-100%) and MIDI-values (0-127)

BEFORE USE

Check the contents:
Check that the carton contains the following items:
 SCENEMASTER unit
 DC-Adapter
 User manual
Some important instructions:
 Before you start using this unit, please check if there's no transportation damage. Should there be any, do
not use the device and consult your dealer first.
 Important: This device left our factory in perfect condition and well packaged. It is absolutely necessary
for the user to strictly follow the safety instructions and warnings in this user manual. Any damage caused
by mishandling is not subject to warranty. The dealer will not accept responsibility for any resulting defects
or problems caused by disregarding this user manual.
 Keep this booklet in a safe place for future consultation. If you sell the fixture, be sure to add this user
manual.
 To protect the environment, please try to recycle the packing material as much as possible.
JB SYSTEMS
®
®
product. To take full advantage of all possibilities, please read these
1/43
OPERATION MANUAL
SCENEMASTER
