Optional Products

5 inch Extension Arm (437A2224) 7 inch Extension Arm (437A2225)
Figure 7 XR2 Extension Arm Assemblies (5 Inch (437A2224), 7 Inch (437A2225))
The MAYFIELD XR2 Extension Arm Assemblies can provide an additional 5 inches (12.7 cm) or
7 inches (17.8 cm) of reach to the components of the XR2 Base Units (A2079, A2079E). Using one of the
extensions will allow the non-radiolucent components of the XR2 base unit to be positioned away from
metal-sensitive imaging systems. Interfacing with some of the new intra-operative imaging systems
can be easier with these new Extension Arm Assemblies.
Note: By design, only one of the Extension Arm Assemblies can be used at a time.
7 Inch Extension Arm (437A2225)
Figure 8 XR2 Base Unit shown with the 7 Inch Extension Arm (437A2225)
Page 10
