6

6 Special Accessories

6.1 Remote control

A remote control adds convenience and is available as a special
accessory. Operation and menu navigation are identical to those
of the heat pump manager. Connection is made using a 6-core
telephone cable (special accessory) with modular plugs.

6.2 Room Climate Control Station

With cooling using panel heating/cooling systems, regulation is
carried out according to the room temperature and humidity
measured by the room climate control station.
This is done by setting the desired room temperature on the heat
pump manager. The minimum
temperature is calculated from the room temperature and
humidity measured in the reference room. The control response
of the cooling system is influenced by the currently measured
room temperature and the set room set temperature.

6.3 Building management technology

The heat pump manager can be connected to a building
management system network via supplementation of the
relevant interface plug-in card. The supplementary installation
instructions of the interface card must be consulted regarding the
exact connection and parameterisation of the interface. 
The following Connections are possible with the heat pump
manager:
 Modbus

6.4 Thermal energy meter

A maximum of 1 thermal energy meters can be connected to the
heat pump manager for thermal energy measurement. Available
thermal energy meters are the WMZ25 and the WMMMMZ32.
The supplementary installation instructions of the thermal energy
meter must be consulted regarding its installation and
parameterisation.
EN-8
possible cooling water
NOTE
In the case of heating controllers with removable control panels (see Kap.
3.2.2 auf S. 3), the operating element can also be directly used as a remote
control.
Fig. 6.1: Room climate control station
 EIB, KNX
Ethernet

ATTENTION!
If the heat pump or circulating pumps are controlled externally, an
additional flow rate switch is required to prevent the compressor
from being switched on when there is no volume flow.
