Defi ning profi les
• Editing an existing profi le (excluding Leister profi les):
– In the working display (28), set the required setpoints using the «Plus»
– In the function display (27), select the Settings menu
– In the «Setup» menu, select «Save Profi le» with the «Plus» key (26)
– Select the profi le you want to edit and confi rm with the relevant key (25)
– In the function display (27), select the «Edit selected item» symbol
(25) .
– Enter the desired profi le name (see "Entering names or passwords" chapter), then select the
with the «Plus» key (26)
– In the function display (27), confi rm the selected «Save» symbol
profi le has now been successfully saved and selected.

Machine setup

and confi rm with the relevant key (25)
Menu Function
Setting the unit used:
Select Unit
– metric/imperial
LED mode:
– ON*: The LED light can only be switched on if the drive is
released. As soon as the drive is released, the LED symbol
appears in the function display (27). This symbol allows you
to switch the LED light on/off as you wish. The LED mode is not
changed.
LED Mode
– ON: The LED light is permanently switched on.
The LED symbol
This symbol allows you to switch the LED on/off as you wish.
The LED mode is not changed.
– OFF: The LED light is permanently switched off .
LCD Contrast Setting the LCD contrast
LCD Backlight Setting the backlight for the display
Key Backlight Setting the backlight for the keyboard
or «Minus»
with the «Plus» key (26)
.
.
and confi rm with the relevant key
.
with the relevant key (25)
is displayed in the function display (27).
keys (24/26).
.
symbol
. The
