Electrical connection

NOTE
All electrical connections must be carried out
by an authorised electrician.
Electrical installation and wiring must be carried
out in accordance with the stipulations in force.
The climate unit must not be powered when
installing MODBUS 40.
F1345 has different electrical connection versions de-
pending on when the heat pump was manufactured. To
check which electrical connection applies to your F1345,
check the designation "2.0" visible above the right hand
side of the terminal block as illustrated.
The electrical circuit diagram is at the end of this Installer
handbook.
Connecting communication
For following connections, use cable type LiYY, EKKX or
similar.
F1145/F1155
Terminal block X1 on the SMS board (AA9) in MOD-
BUS 40 is connected to terminal block X4:9-12 on the
input board (AA3) in the heat pump.
AA3-X4
10
AA3-X4
7
8
9
10
11
12
Heat pump
MODBUS 40
AA9-X1
12V A
B GND
F1245/F1255
Terminal block X1 on the SMS board (AA9) in MOD-
BUS 40 is connected to terminal block X4:9-12 on the
input board (AA3) in the heat pump.
AA3-X4
F1345 without 2.0
Terminal block X1 on the SMS card (AA9) in MODBUS 40
is connected to terminal block X6:4-7 in the heat pump.
AA3-X6
F1345 with 2.0/F1355
Terminal block X1 on the SMS card (AA9) in MODBUS 40
is connected to terminal block AA101-X10:7-10 in the
heat pump.
AA101:X10
-AA101
-X10
1 2 3 4 5
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
A B
A B
A B
13 14
0-10V
-GP16
-FC1
2.0
-AA101
-AA101
-AA101
-X7
-X8
-X9
-AA101
-AA101
-AA101
-AA101
-AA101
-AA3
-X3
-X4
-X5
-X6
-X10
-X6
-AA3
-AA3
N
L1
L2 L3
1 2 3
1 2 3 4 5 6 7 8 9
1 2 3 4 5 6 7 8 9
1 2 3 4
1 2 3
1 2 3
1 2 3 4 5
6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
16 17 18
-X22
-X23
-AA3
1 3 12 3
2
-X20
-X21
L N
L L L N N N
L
N
PE
L N PE
-EP14 -EP15
C
K1
K2 K3
C NO NC
C NO NC
A B
A B
A B
0-10V
13 14
-BF1
QN10
GP16
K4
-AA3-X7
-GP16
AA3-X4
7
8
9
10
11
12
Heat pump
MODBUS 40
AA9-X1
12V A
B GND
X6
4 5 6 7
Heat pump
MODBUS 40
12V A
B GND
AA9-X1
AA101-X10
6 7 8 9 10 11
Heat pump
MODBUS 40
12V A
B GND
AA9-X1
