Colour Calibration = Colour calibration
Autolock = Automatic locking of the
controls
LED Frequency = LED PWM frequency
IR Remote = activate or deactivate control
by IR remote control
Factory Reset = reset to factory settings
Confirm all entries with ENTER.
BATTERY RUN TIME (Runtime)
Battery life can be increased to up to 24 hours by reducing brightness accordingly (see table Settings). Battery life is calculated with
spotlight on full and 100% battery charge status. Battery life is extended considerably if not all of the colours red, green, blue and white are
activated (Full On), instead only red, for example.

DIMMER CURVES

linear
DMX value
SYSTEM INFORMATION (System Info)
Press MODE to access the selection menu. Using the UP and DOWN controls, select the menu item "System Info" (observe arrow) and
confirm with ENTER.
---------------- Menu ----------------
DMX Address
DMX mode
Stand Alone
Slave
Settings
System Info
Use the UP and DOWN controls to select the desired submenu item, and press ENTER to display the corresponding information.
Red, Green, Blue, White
On
Off
800Hz / 1200Hz /
2000Hz / 3600Hz /
12kHz / 25kHz
On
Off
Reset Now!
exponential logarithmic
DMX value
DMX value
Individual colour calibration. Cross-mode bright-
ness setting of the 4 LED groups RGBW with
values from 000 - 255
Automatic locking of the controls after approx-
imately 1 minute of inactivity. Display shown
upon attempted use: "Locked!" To unlock: Press
and hold UP and DOWN simultaneously for
approx. 5 seconds
Automatic locking of the controls is disabled
Configuration of LED PWM frequency
IR remote control activated
IR remote control deactivated
Reset to factory settings:
Confirm with ENTER. Cancel with MODE
S-curve
DMX value
