CLIMA SELECT DB66 Gebrauchsanleitung Seite 36

Open the gas cartridge storage compartment and close the pressure gauge (to close it, turn it counterclockwise).
Place a container under the distribution tap and empty by pulling the handle toward you until nothing flows out any
more.
tube.
Open the keg's compartment door and disconnect the CO
2
Evacuate the remaining gas by using the supplied tool (Fig e‐16)
as shown in the photo to the right :
Then disconnect the beer distribution tube.
Unlock the distribution head from the keg by pushing the latch
and remove the piercing rod from the keg by pulling it vertically
upward.
Hold it in position while pulling the tube from
the rear (move your hand into the place where the
CO cartridge is and grasp the tube (Fig. x)
2
Disconnect the two black plastic endpieces (Fig. y) by turning
the upper endpiece counterclockwise.
Then pull the tube to release it from the lower connector
(Fig y‐2) and remove the upper
connector (Fig. y‐1) to release the tube.
This tube can then be completely removed.
To do this, open the door of the
cooling compartment
and then pull the tube to extract it.
Then slide the new tube through the hole in the wall between the cooling compartment and the CO compartment (Fig.
2
z)
Place the upper connector on the part of the beer outlet tube extending from the wall (Fig. y‐2)
36
