Scanning from TWAIN

The Scan Info Box

The following figure shows the information on the Scan Info box.
Location of the top
left corner of the
image in the
Preview window.
Current location of
the pointer as you
drag it on the
Preview window.

Creating a New Advanced Interface Profile

You cannot change the settings of the preset profiles in the Advanced Interface. However, you can
create new profiles and save them for future use.
To create a new profile:
1. On the Advanced Interface, select one of the preset profiles, for example, Black&White
Configurations/Custom.
2. Adjust the settings as required and then click the Save As button.
The Save Profile dialog box opens.
3. Type a name for the new profile and click OK. The name must be at least two characters long.
Your new profile is added to the configuration list.
To change or delete a profile you created:
1. Select your profile from the configuration list.
2. Make changes to the profile as needed, and then click Save.
3. If you want to delete the selected profile, click Delete.
76 DocuMate 3640
User’'s Guide
Tabs for each selected area. Click a tab to
see the information for its area.
The space on your
computer’'s hard drive.
Physical size of the
image to scan.
Size of the file of the
scanned image.
Click to remove the
selected area.
