adjustiNG the castor aXle aNGle
(Fig.17-18).
Release the screws (1), set the castor angle to 90°. Retighten the
screws.
cautioN!
The castor angle must be set the same on both sides.
(only trough authorized dealers)
seat aNGle
°
= 3
1
FiG. 17
PositioN oF aXle adaPtor
The axle adaptor can be fitted in front of the back tube for better
drive characteristics, or behind it for greater security against tipping
over, (Fig.19).
A larger wheel base gives greater security against tipping over.
To increase the size of the wheel base turn the axle adaptor, (1), to
the rear of the wheelchair.
cautioN!
The wheel locks must be adjusted to match the new position.
1

options - side Guard

staNdard side Guards, FliP-uP, With short or
loNG arMrests
The side guard with rounded off front edges will allow you to get up
close to a table.
To flip the armrest up, push the lever (1), so that the side guard is
released (Fig. 20).
The length of the armrest can be adjusted by releasing the screws
(2), then move the armrest to the desired position and re-tighten the
screws (Fig. 21).
FiG. 20
1
WarNiNG!
Neither the side guards nor the armrests are to be used for lifting or
carrying the wheelchair.
seat aNGle
°
= 0
1
FiG. 18
FiG. 19
FiG. 21
2
sideGuard, FliP-uP, reMovaBle With short or
loNG arMrests, heiGht-adjustaBle
The armrest can be height-adjusted as follows.
Push the lever downwards and move the armrest to the desired
height (3).
Release the lever and press the
armrest downwards until you hear it
click into place. Always check that
the sideguards are correctly in
place.
To flip the armrest up, push the
lever (1) so that the sideguard is
released.
You can adjust the length of the
armrest by releasing the screws (2)
push the armrest to the desired
position and then re-tighten the
screws (Fig. 22).
WarNiNG!
Neither the sideguards nor the armrests are to be used for lifting or
carrying the wheelchair.

options - Back rest

heiGht-adjustaBle BacKrest
The height of the backrest can be
set to 2 different positions (41 cm
and 43.5 cm). Release and remove
the bolts (1), and push the backrest
sling to the desired position. Tighten
up the bolts again (Fig. 23).

options - anti tip tubes

aNti-tiP tuBes
Anti-tip tubes provide additional
safety for inexperienced users when
they are still learning how to
operate their wheelchair. They
prevent a wheelchair from tipping
over backwards.
By pushing on the release button
(1), the safety wheels can be set
upwards or removed. There must
always be a gap of between 3 cm
and 5 cm between the tube and the
ground.
You must swing the safety wheels upwards when going up and
down large obstacles (such as a kerb) to prevent them from
touching the ground. Then rotate the safety wheels back down to
the normal position (Fig. 24).
WarNiNG!
Incorrect setup of the anti-tips will increase the risk of a rearwards
tip.
FiG. 22
1
2
3
FiG. 23
1
FiG. 24
1
11
PariX 2
