DMX operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 13 control channels.
However, it can also be switched to a mode with 4 channels if different functions are required. To be able to
operate the device with a DMX controller, the DMX starting address must be set for the first DMX channel.
The starting address depends upon which DMX controller is being used. Please refer to the controller's
documentation.
1 Press the MENU button so many times until Addr is indicated in the display. Confirm with the ENTER
button.
2 The display indicates 4 CH (4 DMX channels) or 13 CH (13 DMX channels). Use the buttons UP and
DOWN to select the desired number of DMX channels. Confirm with the ENTER button.
3 Now the display indicates the menu item for the DMX start address d***. Use the buttons UP and DOWN
to set the address. Confirm with the ENTER button.
4 The display will not flash when DMX signals are being received. If no control signals are available, the
display will flash.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
Functions in 4-channel mode
Channel
1
Washlight
2
Strobe ring
3
Derby
4
Laser rotation
Value Function
000 – 009 No function
Red
010 – 019
Green
020 – 029
Blue
030 – 039
UV
040 – 049
Red + Green
050 – 059
Green + Blue
060 – 069
Blue + UV
070 – 079
Red + UV
080 – 089
Green + UV
090 – 099
Red + Blue
100 – 109
Red + Green + Blue
110 – 119
Red + Green + UV
120 – 129
Red + Blue + UV
130 – 139
Green + Blue + UV
140 – 149
All LEDs on
150 – 159
Rainbow effect with increasing speed
160 – 209
Rainbow effect + strobe effect with increasing speed
210 – 255
No function
000 – 009
Strobe effect with increasing speed
010 – 255
No function
000 – 009
Forward rotation with increasing speed
010 – 129
Backward rotation with increasing speed
130 – 255
No function
000 – 009
Forward rotation with increasing speed
010 – 119
No rotation
120 – 129
Backward rotation with increasing speed
130 – 255
