Remote control IR-7

The device must be activated for remote control. For this, select "on" in the menu item InFr. When actuating
a button, always direct the remote control towards the sensor on the front panel of the device. There must be
no any obstacles between remote control and the sensor. Remote control is disabled when the device is
operated in DMX or Slave mode.
Notes:
• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the
foil from the battery support on the rear side of the remote control. Otherwise operation of the remote
control is not possible.
• If the range of the remote control decreases, replace the battery. For this purpose,
on the rear side of the remote control press the small bar with the groove to the
right and at the same time remove the battery support. For operation, one 3 V
button cell type CR 2025 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
• Remove the battery from the remote control as a precaution if the device is not used for a longer period of
time.
Button Function
BLACKOUT LEDs off
AUTO Automatic mode; program selection with (+)/(‒)
SOUND Sound control; program selection with (+)/(‒)
STROBE
Strobe effect for automatic mode and sound control;
flash rate setting with (+)/(‒)
SPEED Running speed in
SENSITIVITY Microphone sensitivity; setting with (+)/(‒)
DMX DMX mode
MANUAL Color mode; select colors with R/G/B and UV and (+)/(‒)
UNIT Press <1>: Laser on/off
1-9 Total brightness in manual mode; 1 = dark, 9 = bright
25/32
automatic mode; setting with (+)/(‒)
00116304, Version 1.0
