Power supply of further devices

The jack POWER OUT allows for power supply of further devices. To interconnect several devices, connect
the jack POWER OUT to the input POWER IN of the next unit until all units are connected. Matching power
cables with IEC plugs are available as accessories. In this manner, up to 8 devices can be linked at 230/240
input voltage and up to 4 devices at 110/115 input voltage.

OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the control buttons. All settings remain stored
even if the device is disconnected from the mains. The device can be operated in stand-alone mode via the
control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any commercial DMX
controller.

Menu structure

Mode
Auto mode
Sound control
Running speed in automatic
mode
Microphone sensitivity for
sound control
Silent scene mode
DMX operation
Slave mode
IR remote control
Display
Display
Au – 1
Au – 2
Au – 3
Auto
Au – 4
Au – 5
Au – 6
Au – 7
So – 1
So – 2
So – 3
Sond
So – 4
So – 5
So – 6
So – 7
SPEd SP 1-9
SEnS SE 1-9
on
SILE
oFF
13CH d001-512
Addr
4CH d001-512
SLAU Slave
on
InFr
oFF
dISP
dISP
dSIP
23/32
Function
Program 1: washlight + derby + strobe + laser
Program 2: washlight + derby + strobe
Program 3: washlight + derby + laser
Program 4: derby + laser + strobe
Program 5: derby
Program 6: washlight
Program 7: laser
Program 1: washlight + derby + strobe + laser
Program 2: washlight + derby + strobe
Program 3: washlight + derby + laser
Program 4: derby + laser + strobe
Program 5: derby
Program 6: washlight
Program 7: laser
Program running speed slow > fast
Microphone sensitivity low > high
LEDs switch off if there is no music signal
LEDs remain switched on if there is no music
signal
13-channel mode and start address
4-channel mode and start address
Slave mode
IR remote control on
IR remote control off
Normal representation
Representation turned by 180°
