LED FE-1750 Hybrid Laserflower
DANGER! Electric shock caused by short-circuit
Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires. Never open the housing. Keep the device away from rain and
moisture.
Please read these instructions carefully before using the product. They contain important
information for the correct use of the product.
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet

INTRODUCTION

Thank you for having chosen one of our products. If you follow the instructions given in this manual, we are
sure that you will enjoy this device for a long period of time.

Product features

4in1 LED effect light with derby, washlight, laser (2M) and stroboscope
Rotating derby for mirror ball effects with 6 high-power 3 W RGBAW+UV LEDs (6in1)
•
8 high-power 4 W RGB+UV LEDs (4in1) for washlight and blacklight effects
•
2 laser diodes for of red and green star laser effects
•
Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
•
Strobe ring with 12 cold white 0.5 W SMD LEDs for fast, dynamic strobe effects
•
All effects can be controlled individually
•
Auto, music, master/slave and DMX mode
•
Silent operation
•
7 built-in auto and music show programs
•
Stepless color mixture, dimmer and strobe effect
•
Addressing and setting via control panel with 4-digit LED display
•
Convenient wireless control via included IR remote control EUROLITE IR-7
•
Sound-control via built-in microphone with adjustable microphone sensitivity
•
Supports QuickDMX - the wireless DMX system from Eurolite
•
Built-in phantom-powered USB port for QuickDMX receivers (accessories)
•
DMX512 control possible via any commercial DMX controller
•
4 or 13 DMX channels selectable
•
Swivel mounting bracket
•
Feed-through output allows to power up to 8 devices
•
USER MANUAL
17/32
00116304, Version 1.0
