Read all instructions. Failure to follow
all instructions listed below may result in
electric shock, fire and/or serious injury.
SAVE THESE INSTRUCTIONS.
Intended Use
The machine is intended for hammer drilling in con-
crete, brick and stone as well as for light chiselling
work. It is also suitable for drilling without impact in
wood, metal, ceramic and plastic.
Machines with electronic control and right/left rotation
are also suitable for screw driving and thread cutting.
Noise/Vibration Information
Measured values determined according to EN 60745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level: 91 dB(A);
Sound power level: 102 dB(A).
Uncertainty K = 3 dB.
Wear ear protection!
Total vibration values (vector sum in the three axes)
determined according to EN 60745:
Hammer drilling in concrete: vibration emission value
2
a
= 20 m/s
, uncertainty K = 2 m/s
h
Chiselling: vibration emission value a
2
certainty K = 2 m/s
The vibration emission level given in
this information sheet has been
measured in accordance with a
standardized test given in EN 60745 and may be used
to compare one tool with another.
The vibration emission level will vary because of the
ways in which a power tool can be used and may in-
crease above the level given in this information sheet.
This could lead to a significant underestimate of expo-
sure when the tool is used regularly in such a way.
Note: To be accurate, an estimation of the level of ex-
posure to vibration experienced during a given period
of work should also take into account the times when
the tool is switched off and when it is running but not
actually doing the job. This may significantly reduce
the exposure level over the total working period.
2 609 932 725 • (06.08) T
3 FUNCTION
Product Elements
The numbering of the machine elements refers to the
illustration of the machine on the graphic page.
10 Indicator for the temperature monitoring
11 Battery charged state indicator
12 Button for battery charged state indication
13 Rechargeable Battery*
14 Depth stop
15 Auxiliary handle
16 Screw for drill chuck*
17 Drill chuck*
18 SDS-plus adaptor for drill chuck*
19 Assembled drill chuck*
20 Dust extraction attachment vacuum connection*
2
21 Clamping screw of the dust extraction
2
= 13 m/s
, un-
h
22 Depth stop of the dust extraction attachment*
23 Telescope tube of the dust extraction attachment*
24 Winged screw of the dust extraction attachment*
25 Guide tube of the dust extraction attachment*
26 Universal holder for screwdriver bits*
* Illustrated or described accessory not included as a
standard delivered item.
Declaration of Conformity
We declare under our sole responsibility that this prod-
uct is in conformity with the following standards or
standardization documents:
EN 60745 according to the provisions of the directives
89/336/EEC, 98/37/EC.
21.08.2006, BTI Befestigungstechnik GmbH & Co. KG,
74653 Ingelfingen
English–3
1 Tool holder (SDS-plus)
2 Dust protection cap
3 Locking sleeve
4 Right/Left rotation switch
5 On/Off switch with speed control function
6 Unlocking button
7 Operating mode selector switch
8 Battery unlocking button
9 Button on the auxiliary handle
attachment*
Ulrich Delz
Günter Hub
