Read all instructions. Failure to fol-
low all instructions listed below may re-
sult in electric shock, fire and/or serious
injury.
SAVE THESE INSTRUCTIONS.

Intended Use

The machine is intended for hammer drilling in con-
crete, brick and stone as well as for light chiselling
work. It is also suitable for drilling without impact in
wood, metal, ceramic and plastic.
Machines with electronic control and right/left rotation
are also suitable for screw driving and thread cutting.

Noise/Vibration Information

Measured values determined according to EN 60745.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level: 91 dB(A);
Sound power level: 102 dB(A).
Measuring inaccuracy K = 3 dB.
Wear ear protection!
The typically weighted acceleration is 12 m/s

Declaration of Conformity

We declare under our sole responsibility that this prod-
uct is in conformity with the following standards or
standardization documents:
EN 60745 according to the provisions of the directives
89/336/EEC, 98/37/EC.
Ulrich Delz
BTI Befestigungstechnik Gmbh & Co. KG, 74653 Ingelfingen
1 619 929 704 • (05.06) T
3 FUNCTION
2
.
Günter Hub
English–3

Product Elements

The numbering of the machine elements refers to the
illustration of the machine on the graphic page.
1 Quick change keyless chuck (BTI-BH 2-26 MES)
2 SDS-plus quick change drill chuck
(BTI-BH 2-26 MES)
3 Tool holder (SDS-plus)
4 Dust protection cap
5 Locking sleeve
6 Quick change drill chuck locking ring
(BTI-BH 2-26 MES)
7 Right/Left rotation switch
8 Locking button
9 On/Off switch with speed control function
10 Unlocking button
11 Operational mode selection switch
12 Button on the auxiliary handle
13 Depth stop
14 Auxiliary handle
15 Screw for drill chuck*
16 Drill chuck*
17 SDS-plus adaptor for drill chuck*
18 Assembled drill chuck*
19 Drill chuck receptacle (BTI-BH 2-26 MES)
20 Front sleeve of the quick change keyless chuck
(BTI-BH 2-26 MES)
21 Holding ring of the quick change keyless chuck
(BTI-BH 2-26 MES)
22 Clamping screw of the dust extraction attach-
ment*
23 Depth stop of the dust extraction attachment*
24 Telescope tube of the dust extraction attachment*
25 Winged screw of the dust extraction attachment*
26 Guide tube of the dust extraction attachment*
27 Universal holder for screwdriver bits*
* Not all the accessories illustrated or described are in-
cluded in standard delivery.
