2. Installation
Recommendations
For your safety, connections (water, air and electricity)
should be carried out by an approved installer of dental
equipment. The device requires the following connections
(see technical specifications chapter).
Connect to the drinking water supply using an
automatic cutoff valve of the Aquastop type, or to
the dental chair water supply.
Caution: always turn off the water supply when you
leave the dental practice.

Setting up the equipment

•
Position the device in the place where it is going to be
used.
•
Connect the footswitch (ref. 38) to the connector on
the device(ref. 28).
•
Connect the optional equipment (Team Up ref. 26,
irrigation kit ref. 29).
• Connect the water supply pipe with its filter to the
connector located at the rear of the device (ref. 32).
•
Connect the air supply pipe to the air filter located at
the rear of the device (ref. 27).
•
Plug in the power socket (ref. 35)
• Open the supply taps (water-air).
