Control Panel Navigation
Button Function
MENU to access the menu, quit the current function without saving the setting, or quit the menu
UP to scroll upward in a list of functions or options, or increase a value
DOWN to scroll downward in a list of functions or options, or decrease a value
ENTER to confirm and save a selected option or value
Default Values
The table below provides an overview of the default menu settings:
Feature
DMX address
Built-in static colour
Custom static colour
Built-in program
Program speed
Sound-activated program
Sound sensitivity
Dimmer speed
Remote control
8.

Stand-Alone Mode

In stand-alone mode, the device runs one of the built-in programs. You can also select one of the built-in
static colours, or define your own custom colour.
Note: Make sure to unplug any connection from the DMX input of the device if you want to use it in
stand-alone mode. A device in stand-alone mode may transmit DMX signals that could interfere with the
DMX signals from the controller.
Stand-Alone Mode with Built-in Static Colour
To use one of the built-in static colours:
1. Unplug any connection from the DMX input [8] of the device.
2. Press MENU until <C--> is displayed and press ENTER.
3. Use UP and DOWN to select a colour (C1–C63) and press ENTER to confirm.
4. Press MENU to quit.
Stand-Alone Mode with Custom Static Colour
You can create a custom colour by adjusting the intensity of the red (r), green (g), blue (b), white (W),
amber (A), and purple (P) LEDs.
To use a custom static colour:
1. Unplug any connection from the DMX input [8] of the device.
2. Press MENU until <U--> is displayed and press ENTER.
The last set colour value appears, for example <r215> = red LEDs intensity value = 215.
3. Use UP and DOWN to set the intensity (0–255) and press ENTER.
The next colour value appears.
4. Repeat for all colours until you have the desired output colour.
5. Press MENU to quit.
V. 01 – 29/04/2014
VDPL310FC2
Access the control panel functions using the four panel
buttons [4,6] located near the display [5].
Menu item
3-CH / 8-CH / 12-CH
C--
U--
P--
S--
Snd
SenS
dIM
SET
Default value
12-CH, d--1
C63 (all LEDs on)
r255/g255/b255/w255/a255/p255
P1: 6 colours switching
100 (fast)
Snd1: 6 colours
80
OFF: dimmer speed is off
On: remote control is enabled
