3.

General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
Keep this device away from dust and extreme temperatures. Make sure the ventilation
openings are clear at all times. For sufficient air circulation, leave at least 1" (± 2.5 cm)
in front of the openings.
Protect this device from shocks and abuse. Avoid brute force when operating the
device.

Familiarise yourself with the functions of the device before actually using it. Do not allow operation
by unqualified people. Any damage that may occur will most probably be due to unprofessional use
of the device.

All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.

Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, lamp explosion, crash, etc. Using the device in an unauthorised way will void the
warranty.

Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.

Mechanical wear and LEDs are not covered by warranty.

A qualified technician shall install and service this device.

Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.

This device is designed for professional use on stage, in discos, theatres, etc. The device shall only
be used indoors with an alternating current of 100–240 VAC, 50/60 Hz.

Lighting effects are not designed for permanent operation: regular operation breaks will prolong their
lives.

Keep this manual for future reference.
4. Features
The UNILED 6 is a multi-purpose LED light for every kind of event and installation with powerful RGBWAP
full-colour LEDs. It features a flat bottom and has signal and power connections on the side, so it is
perfect to use as a wall lighter and other kinds of floor applications.

3 x 8 W RGBWAP high-power LED, with white colour temperature pre-set (3200 – 10 000 K)

DMX control via 6, 8, or 12 channels for simple or advanced controlling
o 6 channel mode: RGBWAP
o 8 channel mode: dimmer, RGBWAP, strobe
o 12 channel mode: dimmer, RGBWAP, preset colour, auto program, auto program speed, dimmer
curve

built-in programs with speed adjustment

sound activation via internal microphone with adjustable sensitivity

static colour selection

master/slave mode for synchronized operation of multiple units linked in a chain

flicker-free operation (400 Hz)

with IR remote control.
5. Overview
Refer to the illustrations on page 2 of this manual.
1 double bracket
2 hinge
3 IR receiver for remote control
4
control buttons
V. 01 – 29/04/2014
VDPL310FC2
5 display
6 control buttons
7 safety hook
8
DMX input
4
9 power input + fuse holder
10 power output
11 DMX output
©Velleman nv
