Stand-Alone Mode with Built-in Program
To set the device to stand-alone mode with a built-in program:
1. Unplug any connection from the DMX input [8] of the device.
2. Press MENU until <P--> is displayed and press ENTER.
3. Use UP and DOWN to select a built-in program:
o <P1>: 6 colours switching
o <P2>: 6 colours fading
o <P3>: 63 colours switching
o <P4>: 63 colours fading.
4. Press ENTER to confirm.
5. To set the speed of the program, press MENU until <S--> is displayed. Note: do not press ENTER.
6. Use UP and DOWN to set the speed from slow (1) to fast (100) and press ENTER to confirm.
7. Press MENU to quit.
Dimmer Speed
You can choose a dimmer speed to control the colour transitions in the automatic programs (switching
colours only). The dimmer speed has no effect on static colours.
To set the dimmer speed, proceed as follows:
1. Press MENU until <dIM> is displayed and press ENTER.
2. Use UP and DOWN to select the desired setting:
o <OFF>: dimmer off, for abrupt colour transitions.
o <dIM1>–<dIM3>: dimming speeds 1 (fast) to 3 (slow), for smooth colour transitions.
3. Press ENTER to confirm.
After changing the dimmer speed, you have to reactivate the automatic program, as follows:
4. Press MENU until <P--> is displayed and press ENTER.
5. Use UP and DOWN to select the desired program and press ENTER.
6. Press MENU to quit.
Sound Activation
To use an automatic program with sound activation, proceed as follows:
1. Unplug any connection from the DMX input [8] of the device.
2. Press MENU until <Snd> is displayed and press ENTER to confirm.
3. Use UP and DOWN to select the desired setting:
o <Snd1>: 6 colours changing, responding to sound.
o <Snd2>: 63 colours changing, responding to sound.
4. To change the sensitivity of the internal microphone, press MENU until <SenS> is displayed.
Note: do not press ENTER.
5. Use UP or DOWN to set the sensitivity from low (0) to high (100) and press ENTER to confirm.
6. Press MENU to quit.
9.

Master/Slave Mode

The master/slave mode allows for connecting several devices to a single master device in a daisy chain.
All slave devices will then work synchronously with the master device. The first device in the daisy chain
functions as the master device.
To set the devices to master/slave mode:
1. Unplug any connection from the DMX input [8] of the master device (the first device in the chain).
2. Connect the DMX input of the first slave device to the DMX output [11] of the master device.
3. Connect the DMX input of the subsequent slave devices to the DMX output of the previous slave
device.
4. Set up the unit as described in Stand-Alone Mode.
5. On each slave device, set the DMX address to 1 as follows: press MENU until <12-CH> is displayed
and press ENTER.
6. Use UP and DOWN to set the DMX starting address to <d--1> and press ENTER.
10.

Operation with Remote Control

Note: Make sure to unplug any connection from the DMX input of the device if you want to use it in
stand-alone mode. A device in stand-alone mode may transmit DMX signals that could interfere with the
DMX signals from the controller.
