Familiarise yourself with the functions of the device before actually using it. Do not allow operation
by unqualified people. Any damage that may occur will most probably be due to unprofessional use
of the device.

All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.

Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, lamp explosion, crash, etc. Using the device in an unauthorised way will void the
warranty.

Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.

Mechanical wear and LEDs are not covered by warranty.

A qualified technician should install and service this device.

Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.

This device is designed for professional use on stage, in discos, theatres, etc. The device should only
be used indoors with an alternating current of 230 VAC/50 Hz.

This device is designed for professional use on stage, in discos, theatres, etc. The device should only
be used indoors. Use only the included power adapter.

Lighting effects are not designed for permanent operation: regular operation breaks will prolong their
lives.

There may be some smoke or a particular smell when the device is activated for the first time. This is
normal and any smoke or smell will gradually disappear.

Use the original packaging if the device is to be transported.

Keep this manual for future reference.
4. Features

high power moving head with 200 W Philips 5R lamp

14 colours + white

17 rotating gobos + open; with easy access for a tool-free gobo change

with 8-facet prism, frost, and automatic zoom

DMX controlled by 20 channels

with master/slave and stand-alone mode

pan (540°) and tilt (270°), self-correcting

high-transmittance Fresnel lens, resistant to high temperatures
5. Overview
Refer to the illustrations on page 2 of this manual.
1 Power indicator
2 DMX mode indicator
3 Display
4 Enter button
6. Installation
Choose a suitable mounting spot. Mount the device in the desired angle using the included bracket.
Connect the power cord to the mains. Disconnect after use.
Every unit can be placed on the ground or hanging installation in any position using the brackets.

Mounting the Device


Have the device installed by a qualified person, respecting EN 60598-2-17 and all other applicable
norms.

The carrying construction must be able to support 10 times the weight of the device for 1 hour
without deforming.

The installation must always be secured with a secondary attachment e.g. a safety cable.
V. 03 – 29/01/2013
VDP200MH5R
5 Down button
6 Up button
7 Menu button
